Introduction
The LXLCG series large diameter detachable water meter is designed for measuring total water volume in municipal, industrial, and irrigation pipelines. Featuring a dry-type magnetic drive, the counting device is isolated from water, ensuring accurate readings, long service life, and strong anti-freezing capability.
Main Features
Dry magnetic drive – register not immersed in water, anti-freeze and fog-resistant.
Detachable core – easy repair and maintenance.
High flow capacity and low pressure loss.
Long-lasting accuracy – ±2% at transitional to overload flow, ±5% at minimum to transitional flow.
Optional remote output – pulse 100L, 1000L, or 10000L per pulse.
Vacuum-sealed register – readings remain clear over years.
Working Conditions
Nominal Pressure: ≤1.0 MPa (10bar) or ≤1.6 MPa (16bar)
Water Temperature: Cold water 0.1–30°C, Hot water 0.1–90°C
Accuracy: ±2% from transitional to overload flow; ±5% from minimum to transitional flow
Technical Parameters
|
Nominal Diameter (mm) |
Accuracy Class (Q3/Q1) |
Overload Flow Q4 (m³/h) |
Normal Flow Q3 (m³/h) |
Transitional Flow Q2 (m³/h) |
Minimum Flow Q1 (m³/h) |
Min. Reading (m³) |
Max. Reading (m³) |
|
50 |
50 |
31.25 |
25 |
0.8 |
0.5 |
0.001 |
999999 |
|
65 |
50 |
50 |
40 |
1.28 |
0.8 |
0.001 |
999999 |
|
80 |
50 |
78.75 |
63 |
2.016 |
1.26 |
0.001 |
999999 |
|
100 |
50 |
125 |
100 |
3.2 |
2.0 |
0.001 |
999999 |
|
125 |
50 |
200 |
160 |
5.12 |
3.2 |
0.001 |
999999 |
|
150 |
50 |
312.5 |
250 |
8.0 |
5.0 |
0.01 |
9999999 |
|
200 |
50 |
500 |
400 |
12.8 |
8.0 |
0.01 |
9999999 |
|
250 |
50 |
787.5 |
630 |
20.16 |
12.6 |
0.01 |
99999999 |
|
300 |
50 |
1250 |
1000 |
32 |
20 |
0.1 |
99999999 |
|
350 |
40 |
1750 |
1400 |
56 |
35 |
0.1 |
99999999 |
|
400 |
50 |
2000 |
1600 |
51.2 |
32 |
0.1 |
99999999 |
|
500 |
50 |
3125 |
2500 |
80 |
50 |
0.1 |
99999999 |
Dimensions
|
Nominal Diameter (mm) |
Length L (mm) |
Width B (mm) |
Height H (mm) |
Bolt Hole Center D1 (mm) |
Flange Outer Diameter D2 (mm) |
Bolt Size |
Pressure (MPa) |
Weight (kg) |
|
50 |
200 |
165 |
215 |
125 |
165 |
4-M16 |
1.0 |
10 |
|
65 |
200 |
185 |
223 |
145 |
185 |
4-M16 |
1.0 |
13.5 |
|
80 |
225 |
200 |
233 |
160 |
200 |
8-M16 |
1.0 |
15.5 |
|
100 |
250 |
220 |
288 |
180 |
220 |
8-M16 |
1.0 |
18.5 |
|
125 |
250 |
250 |
298 |
210 |
250 |
8-M16 |
1.0 |
24.8 |
|
150 |
300 |
285 |
342 |
240 |
285 |
8-M20 |
1.0 |
27.6 |
|
200 |
350 |
340 |
369 |
295 |
340 |
8-M20 / 12-M20 |
1.0 / 1.6 |
47.5 / 48 |
|
250 |
450 |
395 |
433 |
350 |
395 |
12-M20 / 12-M24 |
1.0 / 1.6 |
85 / 94 |
|
300 |
500 |
445 |
456 |
400 |
445 |
12-M20 / 12-M24 |
1.0 / 1.6 |
105 / 114 |
|
350 |
500 |
505 |
595 |
460 |
505 |
16-M20 |
1.0 |
125 |
|
400 |
600 |
565 |
632 |
515 |
565 |
16-M24 |
1.0 |
185 |
|
500 |
800 |
670 |
766 |
620 |
670 |
20-M24 / 20-M30 |
1.0 / 1.6 |
320 / 340 |
Optional Remote Transmission
Pulse output (100L, 1000L, 10000L per pulse)
RS485, Modbus, LoRaWAN communication
STS prepaid system support
Internal or external lithium battery supply
